#include <Wire.h>
#define EEPROM_ADDR 0x50           // I2C Buss address of 24LC256 256K EEPROM

void setup()
{
  Wire.begin();                        // join I2C bus (address optional for master)
  Serial.begin(9600);

  // TESTS FOR EACH FUNCTION BEGIN HERE
  Serial.println("Writing Test:");
  for (int i=0; i<20; i++){            // loop for first 20 slots
    i2c_eeprom_write_byte(EEPROM_ADDR,i,i+65);   // write address + 65 A or 97 a
    Serial.print(". ");
    delay(10);                         // NEED THIS DELAY!
  }
  Serial.println("");
  delay(500);

  Serial.println("Reading Test:");
  for (int i=0; i<20; i++){            // loop for first 20 slots
    Serial.print(i2c_eeprom_read_byte(EEPROM_ADDR, i),BYTE);
    Serial.print(" ");
  }

  // setup for page tests . . .
  byte PageData[30];                   // array that will hold test data for a page
  byte PageRead[30];                   // array that will hold result of data for a page
  for (int i=0; i<30; i++){            // zero both arrays for next test
    PageData[i] = 0;
    PageRead[i] = 0;
  }
  Serial.println("");
  for (int i=0; i<30; i++) PageData[i] = i+33;  // fill up array for next test char 33 = !

  Serial.println("Writing Page Test:");
  i2c_eeprom_write_page(EEPROM_ADDR, 100, PageData, 28 ); // 28 bytes/page is max

  Serial.println("Reading Page Test:");
  i2c_eeprom_read_buffer( EEPROM_ADDR, 100, PageRead, 28);
  for (int i=0; i<28; i++){
    Serial.print(PageRead[i],BYTE);    // display the array read
    Serial.print(" ");
  }
}

void loop()
{
}

void i2c_eeprom_write_byte( int deviceaddress, unsigned int eeaddress, byte data )
{
  int rdata = data;
  Wire.beginTransmission(deviceaddress);
  Wire.send((int)(eeaddress >> 8));    // Address High Byte
  Wire.send((int)(eeaddress & 0xFF));  // Address Low Byte
  Wire.send(rdata);
  Wire.endTransmission();
}

// Address is a page address, 6-bit (63). More and end will wrap around
// But data can be maximum of 28 bytes, because the Wire library has a buffer of 32 bytes
void i2c_eeprom_write_page
( int deviceaddress, unsigned int eeaddresspage, byte* data, byte length )
{
  Wire.beginTransmission(deviceaddress);
  Wire.send((int)(eeaddresspage >> 8)); // Address High Byte
  Wire.send((int)(eeaddresspage & 0xFF)); // Address Low Byte
  byte c;
  for ( c = 0; c < length; c++)
    Wire.send(data[c]);
  Wire.endTransmission();
  delay(10);                           // need some delay
}

byte i2c_eeprom_read_byte( int deviceaddress, unsigned int eeaddress )
{
  byte rdata = 0xFF;
  Wire.beginTransmission(deviceaddress);
  Wire.send((int)(eeaddress >> 8));    // Address High Byte
  Wire.send((int)(eeaddress & 0xFF));  // Address Low Byte
  Wire.endTransmission();
  Wire.requestFrom(deviceaddress,1);
  if (Wire.available()) rdata = Wire.receive();
  return rdata;
}

// should not read more than 28 bytes at a time!
void i2c_eeprom_read_buffer( int deviceaddress, unsigned int eeaddress, byte *buffer, int length )
{
  Wire.beginTransmission(deviceaddress);
  Wire.send((int)(eeaddress >> 8));    // Address High Byte
  Wire.send((int)(eeaddress & 0xFF));  // Address Low Byte
  Wire.endTransmission();
  Wire.requestFrom(deviceaddress,length);
  //int c = 0;
  for ( int c = 0; c < length; c++ )
    if (Wire.available()) buffer[c] = Wire.receive();
}
